Wire Inspection, The Navy’s Way

By Jonathan Ray | March 1, 2009
Send Feedback

In the United States Navy, where operational readiness is directly tied to the mission capability of highly complex aircraft, preventive maintenance is the difference between mission success or mission failure.

For more than seven years, the Naval Air Systems Command (NAVAIR) Wiring Systems Branch of the Propulsion and Power Engineering Department has worked to address wiring system problem areas. The training has been compiled from in-service aircraft evaluations to address relative issues that lead to wiring discrepancies.

The Wiring Awareness Inspection Techniques (WAIT) training team travels all over the world to train sailors and Marines. The training makes them aware of the correct processes for proper inspection techniques.

"After attending the WAIT class and observing the fleet maintainer’s reaction to the experience, I believe that this an excellent tool to maintain or even increase all in-service Seahawk RFT (Ready For Training) and safety numbers," said Christopher Rowe, with the H-60 Helicopter Program (PMA-299).

"The information being passed between the fleet maintainers and the wiring assessors will allow for better and more consistent wiring inspection techniques and standards from squadron to squadron. The information will also allow PMA-299 to identify areas to improve both maintenance plan and design."

The WAIT training class is designed to teach sailors how to better identify and correct wiring discrepancies before they have an impact on safety of flight or aircraft wiring systems.

Wiring-related problems in Navy aircraft contribute to an average of 1.1 Class A, 1 Class B, and 1.6 Class C mishaps per year. There have been a total of 37 mishaps in the last 10 years related to aircraft wiring, according to Propulsion System Safety Metrics monitored from Oct. 1, 1998 to March 30, 2008.

The problem most often is due to chafed wire conditions. Improper routing and clamping predominantly cause chafed wire. When these conditions exist, the insulation on the wire wears away and exposes the raw wire. The results can be a simple short that causes an instrument to no longer function or, in more severe cases, a fire that can lead to a class A mishap.

The cause of the chafing can be attributed to any number of things, not excluding maintenance itself. Awareness of the causes of chafed conditions is a key in preventing them. The hands-on class is designed for all maintenance ratings.

"Everyone is an inspector," said Dave Quinzani, WAIT training team lead. "This training attempts to instill a common sense approach to wiring inspection. For example, it’s no surprise that the best tools are a flashlight, mirror and awareness of system problem areas.

"Most training is done on the job," added Quinzani, a former aviation electrician’s mate chief. "These skills are typically mentored from one maintainer to the next, making this on-the-job training very useful throughout the Navy and Marine Corps."

The WAIT class is effective, Quinzani said, because of its hands-on approach. Instructors want to see the maintainers interact with the aircraft. The training heightens the maintainers’ awareness to wiring problem areas.

"You can only get so much from reading a book or looking at slides," Quinzani said. "The hands-on experience brings the text and lessons to life."

WAIT training is a three-day evolution. On the first day, instructors and the command’s collateral duty inspectors/quality assurance representatives (CDI/QAR) assess the installation and condition of the wiring on squadron aircraft. They look for common trends such as chafing and corrosion, photograph problem areas and incorporate the information into a brief given on Day Two.

Day Two is a half-day classroom briefing where instructors teach the problems, causes and remedies of common wiring issues. Part of that time is spent focusing on the previous day’s assessment of the squadron’s own aircraft. For the rest of the day, the class heads out to the hangar, where the assessors and maintainers get their hands dirty practicing new inspection techniques.

The third day combines the training of days one and two, to address issues identified during the assessment. Some discrepancies take just a handful of hours to correct; others will require an investment of several weeks. Either way, the NAVAIR team is confident that passing along more than a few tried-and-true techniques will pay dividends down the line for the unit, the platform and the Navy.

"The class gave me a pretty good perspective on how to respect wire in aircraft," said AT3 Lawrence Callier, of HSC-28 at Naval Air Station Norfolk, Va. "The most important lesson I learned was that ‘problem’ wire could be anywhere. Something could look fine, like nothing is wrong with it, and it could be one of the biggest problems you could have."

"This [WAIT training] class has opened my eyes to things, that even as a QAR, I’ve overlooked just because I didn’t see the importance of it, and no one had trained me the right way to say ‘it should be this way vice that.’ For the junior guys, this is great for them to see how to inspect aircraft wire properly," said AT1 Christopher Chambers, of HSC-28 at NAS Norfolk.

This article originally was published by the U.S. Naval Air Systems Command.
