Astronics Unveils AWG, Digitizer in PXI Portfolio

By S.L. Fuller | January 24, 2017
Send Feedback


Astronics Test Systems now offers the new PXIe-1802 Arbitrary Waveform Generator (AWG) and the new PXIe-1803 Digitizer, parent company Astronics Corporation says. These technologies provide test capabilities and measurement accuracy.

PXI test instruments. Photo: Astronics

The PXIe-1802 works for output frequencies of up to 125 MHz. It has built-in waveforms, high signal quality, high density and modularity, among other features. The AWG delivers dual 14/16-bit waveform generator channels, bandwidths of 90-140 MHz, synchronization and 250 μV measurement accuracy.

A 130/180 MS/s dual-channel digitizer, the PXIe-1803 works for input frequencies up to 175 MHz. The digitizer provides a dual-channel 14/16-bit digitizer configurable as separate or fully synchronized channels. It also features 64M of waveform memory per channel and relative accuracy of up to 0.006 percent, among other items.
